PRODUCTS

Sakkary offers a large bandwidth of machines, from low-cost entry-level models to high-end machines with a variety of control options.

FIBER LASER Laser Machine open type

Part No. 3

Pipe Welding Bed

1.Pipe welding bed, high temperature annealing treatment, reduce the internal stress and deformation, its rigidity is strong, high structural stability, enough to meet the use;
2. The bed is 100mm lower than the old G, and the height of the bed is reduced to facilitate the loading and unloading of the front and side;
3. Shell sheet metal adopts thick sheet metal, which is cut by our own optical fiber machine and processed by bending machine;
4. Under the premise of constant dynamic performance, we optimize the

structure, perfectly integrate the workbench and bed, and directly put the knife blade on the bed to avoid shaking;
5. The new G has removed the roller and simplified the assembly, greatly shortening the production and assembly cycle and producing the equipment in the shortest time.

Cast Aluminum Beam

Aerospace standards cast aluminum beam,high accuracy, good toughness, light weight, corrosion resistance, anti-oxidation, low density, and greatly increase the processing speed.

High Precision Rack and Pinion

Double-rack, double-driver;rack, guide and motor drive all use the international first-line brand, and use laser interferometer to test to ensure cutting accuracy; use the milling cutter to process the ruler more than 5 times to ensure the accuracy of the ruler, the middle of the guide rail and the ruler An adjustment block is installed for adjustment of accuracy.

1. YAG sheet metal laser cutting machine is designed with laser input power 12 kW and laser output power 500 W. Compared to other brands, our products provide a high efficiency of photoelectric conversion, that is, over 4%, while other brands can only reach 2%. Extra electrical energy will convert into heat energy, which may lead to the damage of YAG rod and reduction of device lifetime.
2. These laser cutters adopt good laser beam spot mode, which ensures perfect cutting result for all kinds of sheet metal.
3. With gantry beam flying optics structure and easy light operation, our YAG sheet metal laser cutting machines save about 40% electricity more than other products which adopt fixed optics.
4. During the cutting process, the laser head carries its laser device, which will effect the speed and cutting precision.
5. This type of laser cutter is very suitable for the development of new product. You can use the laser to process it immediately once the drawing is ready and get the object of the new product in a short time.
6. YAG sheet metal laser cutting machine features in the max cutting size 3000×1500mm.o cut materials with yttrium-aluminum-garnet laser. Laser cutting principle is discussed below: ①laser beam is focused into a small spot (max. diameter ≤0.1mm) to achieve a very high power density; ②material surface receives the beam and cutting area material melts, burns or vaporizes away; ③a jet of gas blow away melts or ashes; ④desired cutting edge is left on the material. This kind of cutting technology is characterized by good flexibility. This range of laser cutter can be used to cut sheet metal for any shape and size without moulds. This kind of technology is especially suitable for small batch production of complex shape parts. YAG sheet metal laser cutting machine is widely used in a variety of industries such as advertising and precision machinery. Other applications of the laser cutters includes chassis and cabinet, kitchen ware, hardware,auto parts, metal art, glasses, light, metal pipe, as well as elevator.
Name Specifications

1. YAG sheet metal laser cutting machine is designed with laser input power 12 kW and laser output power 500 W. Compared to other brands, our products provide a high efficiency of photoelectric conversion, that is, over 4%, while other brands can only reach 2%. Extra electrical energy will convert into heat energy, which may lead to the damage of YAG rod and reduction of device lifetime.
2. These laser cutters adopt good laser beam spot mode, which ensures perfect cutting result for all kinds of sheet metal.
3. With gantry beam flying optics structure and easy light operation, our YAG sheet metal laser cutting machines save about 40% electricity more than other products which adopt fixed optics.
4. During the cutting process, the laser head carries its laser device, which will effect the speed and cutting precision.
5. This type of laser cutter is very suitable for the development of new product. You can use the laser to process it immediately once the drawing is ready and get the object of the new product in a short time.
6. YAG sheet metal laser cutting machine features in the max cutting size 3000×1500mm.
