Sakkary offers a large bandwidth of machines, from low-cost entry-level models to high-end machines with a variety of control options.

SN2 series is a two point gap frame press with fabricated steel frame, cast slide and bolster. It is designed for general stamping applications that require larger dies and high precision.
Name Specifications
1. Wintriss WPC 2000 control system meets or exceeds OSHA regulations, and is CSA and ANSI/UL certified.
2. Pneumatic high-torque combination wet clutch and brake provides low noise, long-life operation with minimal maintenance.
3. Rigid frame with minimal angular deflection.
4. Fast response hydraulic overload protection system.
5. Automatic lubrication system with self-monitoring ensures operational reliability.
6. Full length, high precision six point gibs for accurate slide guidance.
7. High accuracy transmission gears and high rigidity crankshafts assures accuracy and long machine life.
8. “Ross” Crossflow dual valve meets category 4 safety standards.
9. Air counter balance system.
10. Motorized slide adjustment.
11. Die height indicator.12. Programmable cam.
13. 6 digit preset counter.
14. Air ejector and outlet.
15. Variable speed main motor.
16. Mis-feed detector.
17. Portable operator T-stand.
